Adaptec 2277500-R 12Gb/s PCIe Gen3 800 Series High Port Count SAS/SATA RAID Card
In stock
SKU
2277500-R
$1,005.00
8805 SAS/SATA 12Gb/s PCIe Gen3 RAID adapter. Low-profile/MD2 8 internal ports 0 external ports 1024MB onboard DDR3 x8 PCI-express RAID 0/1/1E/105/6/50/60 Hybrid 1/10.
Shipping Calculator:
Loading...
| Brand | Adaptec |
| Connector Configuration | Two internal mini SAS HD (SFF-8643) |
| Package Contents |
Adaptec RAID 8805 adapter Additional low profile vented bracket |
| Cache Memory | 1024MB |
| Key Differentiators |
Third generation ZMCP; AFM-700 LP MD2 form factor for up to 16 native SAS/SATA ports |
| Physical Size | 2.535"H x 6.6"L (64mm x 167mm) |
| Customer Needs | High I/O transaction and high bandwidth processing; solutions that reduce energy consumption and maintenance costs. |
| Key Software Features |
Flexible Configuration: HBA Mode & Auto Volume Mode for automatic deployment Optimized Disk Utilization (Multiple Arrays per disk) Supports up to 256 SAS or SATA devices using SAS expanders Support for native 4K sector SAS and SATA devices in addition to 512byte sector devices Supported RAID levels: 0, 1, 1E, 5, 6, 10, 50, and 60 Hybrid RAID 1 & 10 Quick initialization Online Capacity Expansion Performance modes: Dynamic, OLTP & Big Block ByPass Copyback Hot Spare Dynamic caching algorithm Native Command Queuing (NCQ) Background initialization Hot-plug drive support RAID Level Migration Hot spares - global, dedicated, and pooled Automatic/manual rebuild of hot spares SES and SAF-TE enclosure management Configurable stripe size Dual Firmware S.M.A.R.T. support Multiple arrays per disk drive Dynamic sector repair Staggered drive spin-up Bootable array support Support for Tape Devices, Autoloaders MSI-X support for all device driver for all supported Operating Systems Secure boot support for the uEFI host bios USB image available, after shipping, on start.adaptec.com to boot maxView GUI from any USB device for enhanced GUI based setup and offline maintenance |
| Operating System |
Microsoft Windows Red Hat Linux SUSE Linux Fedora Debian Linux Ubuntu Linux Solaris FreeBSD VMware ESXi |
| Benefits | Ideal for 12Gb/s performance-hungry server and workstations platforms, without compromising proven Adaptec reliability. |
| Bus System Interface Type | x8 PCIe 3.0 |
| Form Factor | MD2-Low Profile |
| Management Utilities |
Software Adaptec maxView Storage Manager -Web based GUI Management Utility -OS Support: Windows, Linux, Solaris VMware -Remote configuration, monitoring & notification -Remote firmware updates -SMI-S Support -SMTP ARCCONF -Command Line Interface -SMI-S support for VMware Adaptec BIOS Configuration Utility (CTRL+A) -BIOS level configuration utility -Flashable BIOS support Adaptec uEFI BIOS Configuration Utility -HII based configuration utility -Flashable BIOS support |
| Data Transfer Rate | 12 Gb/s per port |
- Manufacturer Warranty
- 3 Years Limited Warranty
Microsemi 2277500-r Adaptec Raid 8805 Single
| Price | $1,005.00 |
|---|---|
| Product Name | Adaptec 2277500-R 12Gb/s PCIe Gen3 800 Series High Port Count SAS/SATA RAID Card |
| Stock Level | 1-3 Days |
| SKU | 2277500-R |
| Manufacturer Warranty |
|
| Description |
Microsemi 2277500-r Adaptec Raid 8805 Single
|
