D-Link DNR-2020-04P JustConnect 16-Channel PoE 2-Bay Network Video Recorder
In stock
SKU
DNR-2020-04P
$850.00
NETWORK VIDEO RECORDER (NVR) WITH HDMI/VGA OUTPUT 4 POE PORTS 2 BAYS FOR HDD - 16 CHANNELS
Shipping Calculator:
Loading...
| Brand | D-Link |
| Recording |
Max recording bitrate: 80 Mbit/s Primary video profile: H.264 at 1080p at 480 fps Secondary video profile: H.264 at VGA at 240 fps |
| Audio |
Synchronised audio & video recording Audio Compression Format G.711, G.726 |
| Features |
Alarm Recording Pre-alarm: 60 seconds per channel Post-alarm: 300 seconds per channel Remote Live View Supported via browser and Multi NVR Viewer (DCS-260) software Remote Live View Control Live view Preset/Go to Preset Patrol/Auto Patrol Focus PTZ control Snapshot Full screen Auto scan Digital zoom (Zoom in & Zoom out) Manual Record Audio Enable Adjust audio volume Video layout e-map Remote Playback Control Normal Fast forward/rewind Step forward/rewind Remote Playback Supported via browser and Remote Playback application Playback system with timeline GUI, search by event, area, cameras, date, and time Browser or Remote Playback support 16-channel simultaneous playback Digital zoom Overwrite Recording Auto recycling when disk storage is full File Export Local: Export videos to AVI / MP4 format Remote: Export videos to AVI or ASF file Export images to JPG file Digital Watermark Tool Prevents recorded video files/snapshots from being tampered with Acts as a tool for verification User Account Additional accounts can be created to allow users system access and specify authorization for camera channels, PTZ, etc. DDNS D-Link DDNS and DynDns server support Manual DDNS System Time D-Link NTP Input time Sync with computer Daylight saving time Auto Backup Backup recorded data to USB/SAMBA/FTP via a schedule Remote Backup Remote backup software can backup raw data to redundant storage System Status Camera status HDD status System status Network Service |
| Standalone DVR Specifications | Standalone DVR Specifications |
| Video |
Recording Performance Max recording bitrate: 80 Mbit/s Primary video profile: H.264 at 1080p at 480 fps Secondary video profile: H.264 at VGA at 240 fps Camera Search UPnP ONVIF Audio and Video Recording Synchronised audio & video recording Compression Format H.264, MPEG-4, M-JPEG Audio Compression Format G.711, G.726 Video Setting Resolution Quality Bitrate Frame rate Enable audio Video profile selection Recording Mode Record by schedule, manual, always, and event-based recording Motion-triggered recording Alarm Recording Pre-alarm: 60 seconds per channel Post-alarm: 300 seconds per channel |
| Package Contents |
JustConnect 16-Channel PoE Network Video Recorder Power Adapter Ethernet Cable Quick Installation Guide CD-ROM with: Software Product Documentation |
| General |
Standards IEEE 802.3u/x/z IEEE 802.3af SATA II/III Auto MDI/MDI-X HDD2 Format Disk Up to 16 TB HDD EXT3 file system RAID 0, 1, JBOD4 Two Reset Modes Reset firmware GUI button HW reset button (hold for 10 seconds) Reset Button Reset to factory default Flash ROM 128 MB RAM 1024 MB DDR3 Network Interface Gigabit Ethernet port (10/100/1000 Mbps) I/O Ports 1 x 10/100/1000 BaseT RJ-45 port 4 x 10/100 BaseT PoE port (802.3af) HDMI (supports 720p and 1080p resolution with 16:9 display ratio) D-sub for VGA output 1 x USB 3.0 port3 1 x USB 2.0 port3 3.5 mm audio input x 1, output x 1 4 x DI, 1 x DO Cooling 1 x Smart Fan |
- Manufacturer Warranty
- Limited Product Lifetime Warranty
- Manufacturer Contact Info
-
http://www.dlink.com.au/tech/
1300 766 868
D-Link DNR-2020-04P JustConnect 16-Channel PoE 2-Bay Network Video Recorder
| Price | $850.00 |
|---|---|
| Product Name | D-Link DNR-2020-04P JustConnect 16-Channel PoE 2-Bay Network Video Recorder |
| Stock Level | In stock |
| SKU | DNR-2020-04P |
| Manufacturer Warranty |
|
| Description |
D-Link DNR-2020-04P JustConnect 16-Channel PoE 2-Bay Network Video Recorder
|
